Features
- Self‑leveling, 3‑plane (3 × 180°) projection
- Green laser beams for higher visibility
- Accuracy: ±1/8 in. at 33 ft.
- Runtime: up to 8 hours per charge (on maximum brightness)
- Fast charge (~30 minutes) with compatible USB‑PD adapter; can be used while plugged in
- Remote control functionality (remote sold separately; up to ~330 ft range)
- Fine adjustment knob for positioning
- Integrated rare‑earth magnets and tripod mounting threads (5/8"‑11 and 1/4" threads)
- IP54 overmolded housing (water and dust resistance)
- Compact design to fit between studs and in tool pouches
Specifications
| Laser Accuracy | ±1/8 in. @ 33 ft. |
| Laser Beam Color | Green |
| Laser Beam Projection | 3 × 180° |
| Visual Range | Up to 100 ft (visual) |
| Maximum Range (With Detector) | Up to 260 ft using DW0892G detector (sold separately) |
| Runtime | Up to 8 hours per charge (on maximum brightness) |
| Charge Time | Approximately 30 minutes with compatible USB‑PD adapter (adapter sold separately) |
| Remote Control Range | Up to 330 ft (remote sold separately) |
| Mounting | Integrated rare‑earth magnets; tripod threads 5/8"‑11 and 1/4" |
| Ip Rating | IP54 |
| Included Items | USB‑rechargeable laser unit, USB‑C‑compatible cable, mounting plate, storage case |
| Warranty | 3 Year Limited Warranty; 1 Year Free Service; 90 Days Satisfaction Guarantee |
| Country Of Origin | China |
| Opt Sku | DW-DCLE14301GB |
| Mpn | DCLE14301GB |
| Upc/Gtin | 885911996594 |
| Shipping Weight (Lb) | 3.80 |
Related Tools
Related Articles
Self-leveling three‑plane line laser with green beams. Rechargeable via USB (USB-C cable included) with up to 8 hours runtime per charge and a short (~30 minute) charge time when used with a compatible USB‑PD adapter. Produces three 180° lines with ±1/8 in. accuracy at ~33 ft. Visible up to ~100 ft; using a compatible detector extends range to approximately 260 ft. Unit supports remote control (sold separately), has multiple mounting options, and an IP54‑rated housing.
Project Ideas
Business
On-Site Laser Layout Service
Offer a mobile layout service to builders and remodelers: level reference lines for tile setters, plumb lines for framers, cabinet and trim reveal lines, stair rail layout, and drop ceiling heights. The 3-plane projection speeds multi-surface marking, while magnets and tripod threads fit diverse jobsite conditions. Bill by the hour or per room, and upsell with a compatible detector for outdoor or long-range layout.
Crisp Stripe Painting and Wall Graphics
Specialize in perfectly straight accent stripes, gym/school lines, and corporate wall graphics. The self-leveling green beams make taping fast and consistent across long corridors and around corners. Use the remote (optional) to adjust lines from lifts or ladders. Package fixed-price rooms or linear-foot rates, and showcase before/after photos to win commercial and residential clients.
Cabinet, Trim, and Floating Shelf Install
Market an installation service focused on dead-level cabinets, co-planar floating shelves, and consistent trim reveals. The horizontal plane sets continuous elevation marks across rooms; vertical planes ensure perfect plumb for tall cabinets and casing. Promote tighter tolerances and faster installs thanks to ±1/8 in. accuracy, with QA photos showing the laser on during set.
Event/AV Staging Alignment
Serve event companies by aligning LED walls, stage headers, projection screens, and lighting truss. The bright green lines are easy to see in low light, and the 330 ft remote range (optional) is ideal when the unit is on a stand across the stage. Keep the unit powered via USB for long builds. Charge per day plus setup labor, and bundle with tape marks and cable management.
DIY Rental Kits + Tutorials
Build weekend rental packages for homeowners: the laser, tripod, magnetic base, and a quick-start guide for accent walls, tile backsplashes, and gallery walls. Include QR-linked video tutorials you produce, plus add-on consumables (tape, chalk, shims). Offer delivery/pickup and an optional virtual consult to plan the layout, generating revenue from both rentals and coaching.
Creative
Wraparound Geometric Accent Wall
Project the three 180° planes to create continuous level and plumb reference lines that wrap from wall to ceiling to adjacent walls. Tape and paint crisp multi-width stripes or chevrons that stay perfectly aligned through corners. The green beams are easy to see in bright rooms, and the fine adjustment knob lets you micro-shift patterns without moving the base. Use magnets on corner bead or a tripod to keep the unit steady while you tape and spray.
Herringbone Tile Backsplash/Shower
Use the horizontal and vertical planes to establish a square, dead-level datum and a plumb centerline for complex patterns like herringbone or chevron. The 360° coverage keeps your course lines visible around inside corners and niches, while ±1/8 in. at 33 ft accuracy ensures consistent grout lines. Mount on a tripod or snap the magnetic base to steel studs and work hands-free.
Suspended Wood Slat Ceiling Feature
Lay out a floating slat ceiling or cloud by setting a perfectly level perimeter line around the room with the horizontal plane, then use the vertical planes to mark consistent slat spacing across the entire span. The laser’s visibility up to ~100 ft makes it practical in larger rooms; you can keep it plugged in for long install days. The IP54 housing offers dust resistance when cutting and sanding.
Large-Format String Art Mural
Create a modern string art installation on a wall or panel by using intersecting laser planes to locate nail/screw anchor points in precise grids or radiating patterns. The 3×180° projection lets you map lines across corners to make designs that wrap onto an adjacent wall. Remote control (if added) lets you tweak line positions from a ladder while you place anchors.
Epoxy Inlay Coffee Table with Geometric Inset
Use the laser to strike parallel and perpendicular layout lines on a slab or plywood top for crisp, symmetric inlay channels. The 360° lines help mirror patterns across edges for waterfall effects. After routing along a straightedge aligned to the laser, pour dyed epoxy and sand flush for sharp, repeatable geometries without complex jigs.
