DeWalt Battery Cleat – Single

A compact fix for battery chaos

Shop upgrades that actually change daily habits tend to be the small ones. For me, this little yellow battery cleat did exactly that. Instead of setting packs on shelves, stacking them on chargers, or losing them under a bench, I now slide each one onto a dedicated spot on the wall. It’s a simple piece of metal, but it’s well-thought-out for DeWalt users and integrates cleanly into a workshop.

What it is and how it’s built

The cleat is a single, metal wall mount designed to hold one DeWalt battery—12V, 20V MAX, or FLEXVOLT. It’s slim (about an inch wide), bright yellow, and feels rigid in hand. The finish has held up to incidental bumps and the usual grit that a wall near a bench collects. Because it’s metal, there’s no flex when you insert or remove a pack, and the hook profile matches the battery’s rail interface so the pack slides on and locks with a reassuring stop. Rated for up to 5 pounds, it’s comfortable with anything from compact 2Ah 20V packs to large FLEXVOLT bricks.

What I appreciate most in the design is that it uses the battery’s built-in slide and latch system, so the terminals face the cleat and are protected. That means no open contacts collecting dust or getting dinged on a shelf edge. Removing a pack is just as familiar: press the release tabs and slide it off.

Installation and setup

Installation is straightforward. The cleat ships with two wood/drywall fasteners. Here’s what worked well for me:

• Find a stud if you can. Two screws into a stud give you maximum pull-out strength, especially if you plan to hang heavier FLEXVOLT packs. If you’re on drywall only, use appropriate anchors rated for the load.
• Height and spacing matter. I installed a row above my charger so I could grab a charged pack and park the empties quickly. For a tidy look, space multiple cleats on 4–5 inch centers. That gives clearance for release buttons and fingers, even with larger batteries.
• Pilot holes help. A quick 1/8-inch pilot kept the screws straight and avoided cracking the wall finish.
• Consider your workflow. I grouped a few cleats by tool type—one cluster for drilling/fastening, another near the miter saw—so the right battery is always within reach.

The included screws drove in cleanly and bit firmly into the stud. If your wall is masonry or steel, plan to use appropriate anchors or fasteners; this is a simple bracket, so installation is only as strong as the substrate.

Day-to-day use

In practice, the cleat does exactly what it should: it holds a battery securely and makes it easy to put away. Packs slide on vertically from the top and stop positively; there’s no wobble, and no need to “find” the alignment after the first few uses. The weight rating is generous relative to the heaviest DeWalt packs I own, and I’ve had zero concerns about the bracket bending or the battery creeping over time.

Because the face of the battery sits off the wall, the release buttons are accessible, and the LED fuel gauge (where applicable) can still be checked. The yellow finish is easy to spot in peripheral vision, which sounds minor but helps—my wall storage is busy, and color cues speed things up.

I also like that the cleat keeps batteries off flat surfaces where they pick up filings and sawdust. With the contacts tucked against the mount, I’ve seen less grime around the terminals, and any dust that does land is easier to blow off than if the pack were sitting horizontal.

Compatibility and capacity

I tested the cleat with:

• 12V compact packs
• 20V MAX packs from slim 2Ah up through high-capacity
• FLEXVOLT packs

All slid on without drama and stayed put. The 5-pound rating leaves a wide margin even for the largest FLEXVOLT batteries, which are well under that limit. If you’re mixing different battery families on the same wall, these cleats do a nice job of standardizing storage—everything parks the same way, and you can glance across a row and instantly see what’s charged and what’s in use.

Organization benefits

The biggest win is workflow. Charging, grabbing, and returning batteries becomes a single, predictable motion. No toolboxes to open, no shelf piles to manage. I mounted a cleat next to each charger: full packs live on the wall, empties go to the charger, and charged packs return to their spots. That feedback loop keeps me from guessing what’s ready.

There’s also a small but real safety improvement. Fewer loose batteries on flat surfaces means fewer chances of something metallic bridging contacts, even momentarily. The way the cleat captures the battery’s interface protects that area and keeps terminals facing away from the general clutter of a bench.

Part of a bigger system

This cleat is part of DeWalt’s modular workshop storage ecosystem. Even though it mounts directly to a wall with two screws, it plays nicely with the rest of the lineup in terms of spacing, look, and the idea of single-purpose hooks and brackets. If you’re already using DeWalt’s wall-storage components, this fits right in. If you’re not, it still works as a standalone solution—there’s no proprietary rail required here.

Durability and maintenance

After repeated swaps, the metal shows minimal wear at the contact points where the battery rail slides. The finish hasn’t flaked, and the bracket hasn’t loosened. I gave the screws a quick snug after a few days (habit more than need), and they haven’t budged since. Maintenance is essentially nil: an occasional wipe keeps dust down, and that’s the extent of it.

Because it’s metal, I expect better longevity than many plastic alternatives, especially in cold shops where plastic can get brittle. The simple geometry also means less to break—no spring clips, no moving parts beyond your battery’s own latch.

Small quibbles

• It’s a single-battery solution. If you want to store a lot of packs, you’ll need multiple cleats, and that can add up in wall space.
• The included fasteners are fine for wood and drywall, but they’re not universal. On block or metal studs, you’ll need different hardware.
• Orientation options are limited. It’s designed for vertical use. That’s fine and expected, but if you’re planning something creative (like mounting under a shelf), make sure the release buttons remain accessible.

None of these are deal-breakers; they’re nudges to plan your layout and hardware choice carefully.

Value compared to alternatives

There are plenty of ways to store batteries: shelves, 3D-printed brackets, generic rails, and multi-bay stations. The cleat’s strengths are its metal construction, tight fit with DeWalt packs, and small footprint. If you’re already invested in DeWalt tools, the fit-and-finish advantage over generic or printed options is noticeable. If you need high-density storage (say, a dozen packs in a narrow column), dedicated multi-bay racks might be more efficient. For flexible, modular placement, this cleat is a better match.

Warranty and support

DeWalt backs the cleat with a 3-year limited warranty, a 1-year free service period, and a 90-day satisfaction guarantee. For a simple bracket, that support is generous and aligns with the brand’s broader tool ecosystem. It’s a low-risk purchase that you can return or replace if something isn’t right.

Who it’s for

• DIYers and pros with a handful of DeWalt batteries who want to keep them visible and protected
• Small shops looking to keep chargers clear and batteries off benchtops
• Van and trailer setups where vibration-safe, compact storage is useful (as long as you fasten into solid backing)

If you’re using a mix of brands or need one system to hold everything, you’ll want a universal rack instead. But for DeWalt-only setups, this is a clean solution.

Recommendation

I recommend the battery cleat. It’s sturdy, compact, and purpose-built for DeWalt packs. The metal construction inspires confidence, the 5-pound rating covers every pack I own, and the slide-on interface protects terminals while keeping batteries easy to grab. Installation is simple with the included screws, and the bright, slim design makes it easy to build a neat, modular wall layout. If you want to stop hunting for packs and keep your chargers from becoming storage shelves, this small bracket makes a meaningful difference with minimal fuss.
